Technical Specifications
|
Measurement parameters |
More than 80 parameters, including COD, ammonia nitrogen, total phosphorus, total nitrogen, copper, iron, nickel, hexavalent chromium, phosphate, nitrite, pH and residual chlorine, can be customized as required |
|
Wavelength |
340nm, 420nm, 440nm, 470nm, 520nm, 540nm, 560nm, 610nm, 630nm, 660nm, 680nm and 700nm (Any wavelength within the above range can be customized; pH, conductivity and dissolved oxygen can be selected as required) |
|
Indication error |
≤±5 % |
|
Repeatability |
≤±2% |
|
Optical stability |
Absorbance drift ≤0 .002A/20min |
|
Curve and Storage |
200 factory calibration curves, 3500 user-defined curves; Can store 100,000 records. |
|
Display |
5 inch 800*480 color touchscreen |
|
Printer |
Built-in thermal printer |
|
Dimension |
387mm*292mm*134mm |
|
Weight |
2.6kg |
|
Power consumption |
30W |
|
Data interface |
USB |
|
Working environment |
(1) Ambient temperature: 5~40℃ ⑵ Relative humidity: ≤85% ⑶ Power supply: AC 220 (165V-240V) (4) No significant vibration and electromagnetic interference, avoid direct sunlight. |
Measurement Parameters and Accuracy
|
No. |
Measurement item |
Measuring range |
Unit |
Indication error |
|
1 |
COD Cr |
5-200/5-150 |
mg/L |
5% |
|
2 |
COD Cr |
200-2000/150-2000 |
mg/L |
5% |
|
3 |
Ammonia nitrogen(Low range) |
0.00-5.00 |
mg/L |
3%(F.S) |
|
4 |
Ammonia nitrogen(High range) |
5.00-25.00 |
mg/L |
3%(F.S) |
|
5 |
Total phosphorus(Low range) |
0.00-2.00 |
mg/L |
5%(F.S) |
|
6 |
Total phosphorus(High range) |
2.00-10.00 |
mg/L |
5%(F.S) |
|
7 |
Total nitrogen(Low range) |
0.00-10.00 |
mg/L |
5%(F.S) |
|
8 |
Total nitrogen(High range) |
10.0-100.0 |
mg/L |
5%(F.S) |
|
9 |
CODMn(Permanganate index) |
0.00-10.00 |
mg/L |
0.2或5% |
|
10 |
Residual chlorine(Low range) |
0.00-2.00 |
mg/L |
0.1或5% |
|
11 |
Residual chlorine(High range) |
2.0-10.0 |
mg/L |
5% |
|
12 |
Total chlorine(Low range) |
0.00-2.00 |
mg/L |
0.1或5% |
|
13 |
Total chlorine(High range) |
2.0-10.0 |
mg/L |
5% |
|
14 |
Chlorine dioxide(Low range) |
0.00-2.00 |
mg/L |
0.2或5% |
|
15 |
Chlorine dioxide(High range) |
2.0-20.0 |
mg/L |
5% |
|
16 |
Sulfate |
0.0-200 |
mg/L |
5%(F.S) |
|
17 |
Nitrate(Nitrogen) |
0.00-10.00 |
mg/L |
0.1或5% |
|
18 |
Phosphate(Low range) |
0.00-10.0 |
mg/L |
0.2或5% |
|
19 |
Phosphate(High range) |
10.0-50.0 |
mg/L |
5% |
|
20 |
Nitrite nitrogen(Low range) |
0.00-1.00 |
mg/L |
0.05或5% |
|
21 |
Nitrite nitrogen(High range) |
1.0-5.0 |
mg/L |
5% |
|
22 |
Sulfide |
0.00-1.00 |
mg/L |
5%（F.S) |
|
23 |
Fluoride |
0.00-10.0 |
mg/L |
5%(F.S） |
|
24 |
Cyanide |
0.00-0.50 |
mg/L |
5%(F.S) |
|
25 |
Bromide |
0.00-5.00 |
mg/L |
5%(F.S) |
|
26 |
Formaldehyde |
0.00-2.50 |
mg/L |
5%(F.S) |
|
27 |
Volatile phenol(Low range) |
0.00-5.00 |
mg/L |
5%(F.S) |
|
28 |
Volatile phenol(High range) |
5.0-10.0 |
mg/L |
5%(F.S) |
|
29 |
Hydrazine |
0.00-0.50 |
mg/L |
5%(F.S) |
|
30 |
Aniline compound(Low range) |
0.00-1.00 |
mg/L |
5%(F.S) |
|
31 |
Aniline compound(High range) |
1.0-5.0 |
mg/L |
5%(F.S) |
|
32 |
Silicon dioxide |
0.00-5.00 |
mg/L |
5%(F.S) |
|
33 |
Silicate |
0.00-6.00 |
mg/L |
5%(F.S) |
|
34 |
Total alkalinity(Low range) |
0-100 |
mg/L |
5%(F.S) |
|
35 |
Total alkalinity(High range) |
100-1000 |
mg/L |
5%(F.S) |
|
36 |
Total hardness |
0.00-500 |
mg/L |
5%(F.S) |
|
37 |
Chloride ion(Chloride) |
0.00-100.0 |
mg/L |
5%(F.S) |
|
38 |
Ozone |
0.00-2.50 |
mg/L |
5%(F.S) |
|
39 |
Anionic surfactant |
0.00-1.00 |
mg/L |
5%(F.S) |
|
40 |
Ammonium ion(Low range) |
0.00-2.50 |
mg/L |
5%(F.S) |
|
41 |
Ammonium ion(High range) |
2.5-25.0 |
mg/L |
5%(F.S) |
|
42 |
Available chlorine |
0.0-200 |
mg/L |
5%(F.S) |
|
43 |
Chlorite |
0.00-20.0 |
mg/L |
5%(F.S) |
|
44 |
Cyanuric acid |
0-200 |
mg/L |
5%(F.S) |
|
45 |
Urea |
0.00-4.00 |
mg/L |
5%(F.S) |
|
46 |
Copper(Low range) |
0.00-1.00 |
mg/L |
5%(F.S) |
|
47 |
Copper(High range) |
1.0-10.0 |
mg/L |
5%(F.S) |
|
48 |
Zinc |
0.00-5.00 |
mg/L |
5%(F.S) |
|
49 |
Nickel(Low range) |
0.000-0.500 |
mg/L |
5%(F.S) |
|
50 |
Nickel(High range) |
0.50-1.00 |
mg/L |
5%(F.S) |
|
51 |
Nickel |
0.00-10.00 |
mg/L |
5%（F.S) |
|
52 |
Iron(Low range) |
0.00-5.00 |
mg/L |
5%（F.S) |
|
53 |
Iron(High range) |
5.0-10.0 |
mg/L |
5%(F.S) |
|
54 |
Ferrous(Low range) |
0.00-5.00 |
mg/L |
5%（F.S) |
|
55 |
Ferrous(High range) |
5.0-10.0 |
mg/L |
5%(F.S) |
|
56 |
Hexavalent chromium |
0.00-1.00 |
mg/L |
5%(F.S) |
|
57 |
Cadmium |
0.05-0.50 |
mg/L |
5%(F.S) |
|
58 |
Trace Manganese(Low range) |
0.01-0.10 |
mg/L |
5%(F.S) |
|
59 |
Trace Manganese(High range) |
0.10-1.00 |
mg/L |
5%(F.S) |
|
60 |
Manganese |
0.00-5.00 |
mg/L |
5%(F.S) |
|
61 |
Total chromium |
0.00-1.00 |
mg/L |
5%(F.S) |
|
62 |
Aluminum(Low range) |
0.00-0.50 |
mg/L |
5%(F.S) |
|
63 |
Aluminum(High range) |
0.5-5.0 |
mg/L |
5%(F.S) |
|
64 |
Silver |
0.00-1.00 |
mg/L |
5%(F.S) |
|
65 |
Molybdenum |
0.00-1.00 |
mg/L |
5%(F.S) |
|
66 |
Arsenic(Low range) |
0.000-0.500 |
mg/L |
5%(F.S) |
|
67 |
Arsenic(High range) |
0.50-5.00 |
mg/L |
5%(F.S) |
|
68 |
Beryllium |
0.00-0.10 |
mg/L |
5%(F.S) |
|
69 |
Boron |
0.00-2.00 |
mg/L |
5%(F.S) |
|
70 |
Mercury |
0.000-0.500 |
mg/L |
5%(F.S) |
|
71 |
Lead |
0.00-0.50 |
mg/L |
5%（F.S) |
|
72 |
Antimony |
0.00-10.00 |
mg/L |
5%(F.S) |
|
73 |
Barium |
0-100 |
mg/L |
5%(F.S) |
|
74 |
Color(Low range) |
0-50.0 |
PCU |
3%(F.S) |
|
75 |
Color(High range) |
50-500 |
PCU |
3%(F.S) |
|
76 |
Turbidity |
0-400 |
NTU |
≤2%(F.S) |
|
77 |
Turbidity |
0-1000 |
NTU |
≤2%(F.S) |
|
78 |
Suspended solids |
0-1000 |
mg/L |
≤2%(F.S) |
|
79 |
pH(Colorimetric method) |
5.00-8.00 |
PH |
0.1±0.1pH |
|
80 |
pH(Electrode method) |
0.00-14.00 |
PH |
±0.1pH |
|
81 |
Dissolved oxygen (Colorimetric method) |
0.0-10.0 |
mg/L |
0.1±5% |
|
82 |
Dissolved oxygen (Electrode method) |
0-20.0 |
mg/L |
±0.2 |
|
83 |
Conductivity(Electrode method) |
0.00µs/cm-199.9ms/cm |
ms/cm |
±1.0% (F.S) |
|
84 |
TDS (Electrode method) |
0.0mg/L～199.9g/L |
g/L |
±0.5% (F.S) |
|
85 |
Salinity (Electrode method) |
0-10000mg/L |
mg/L |
±1.0% (F.S) |
|
86 |
ORP (Electrode method) |
±2000mV |
mV |
±0.1%（F.S） |
