Shen ChangHong
Product Details
Custom Matching
Technical specifications
Measurement parameter | BOD5 |
Measurement range | 0~4000mg/L |
Analytical method | Mercury-free pressure differential method (magnetic stirring) |
Testing standard | HJ505-2009 5-Day BOD test |
Measurement period | 1-30 days |
Incubation temperature | 20±1℃ |
Processing capacity | 6 samples per run |
Incubation Bottle Capacity | 580ml |
Dimension | 272mm×185mm×75mm |
Weight | 2.4kg |
Power consumption | 10W |
Working environment | (1) Ambient temperature: 5~40℃ ⑵ Relative humidity: ≤85% ⑶ Power supply: DC 15V/2A (4) No significant vibration and electromagnetic interference, avoid direct sunlight. |
Functional features
Six independent test terminals, allowing new measurement groups to be added at any time during the testing process.
Directly reads BOD concentration values without the need for calculations.
Mercury-free differential pressure design ensures high accuracy, eliminates the need for conversions, and guarantees safety and health for the operator.
No tubing design in the experimental process avoids issues like tubing aging and air leaks.
Measurement range is selectable; no dilution required when water sample concentration is below 4000 g/L.
The analyzer automatically records measurement data; one test cycle can select up to 60 sampling points for more precise data.
Adjustable incubation period, customizable based on needs.
Automated measurement process with no need for dedicated supervision.
Large LCD display, intuitive and clear, with easy project selection.
Test terminals come with a high-capacity battery, lasting over 2 years, ensuring no disruption from short-term power outages during testing.
Packing list
1 BOD tray main unit
6 BOD test terminals
6 culture bottles
6 stirring bars
6 reagent cups
1 set of nutrients/buffers
1 bottle of sodium hydroxide
1 set of glucose/glutamic acid (standards)
1 bottle of microorganisms
1 power adapter
1 culture bottle rack
1 plastic tweezers
1 set of precision pH test strips
1 user manual, 1 warranty card, and 1 certificate of conformity
